Ua hauj lwm hauv paus ntsiab lus ntawm semi-automatic high-precision flat labeling
Covsemi-automatic high-precision flat labeling tshuab yog ib lub tshuab tsis siv neeg, semi-automatic ca labeling tshuab dav siv hauv kev lag luam xws li tshuaj pleev ib ce, zaub mov, khoom ua si, tshuaj txhua hnub, hluav taws xob, thiab tshuaj. Cov piv txwv ntawm daim ntawv thov muaj xws li sau npe rau cov tshuaj zawv plaub hau, lub thawv ntim, lub raj mis, lub plhaub yas, thiab lwm yam. Cov hauv qab no qhia txog lub hauv paus ntsiab lus ntawm kev ua haujlwm ntawm lub tshuab labeling thiab yuav ua li cas los kho cov ntawv cim npe.
Txoj haujlwm ua haujlwm:
Manually tso lub workpiece kom sau npe nyob rau hauv ib qho chaw ruaj khov → kauj ruam ntawm ko taw hloov → nias daim ntawv lo lub tog raj kheej → nias lub tshuab nqus tsev nqus lub tog raj kheej → daim ntawv lo lub tog raj kheej tshem tawm mus rau sab xis, tev tawm daim ntawv lo uas tom qab nqus lub taub hau → daim ntawv npog lub tog raj kheej nias daim ntawv lo rau ntawm qhov chaw ua haujlwm → txhua lub tog raj kheej rov pib dua → lub traction motor tig, rub daim ntawv lo rau hauv qhov chaw qub. Qhov no ua tiav ib lub voj voog ntawm kev sau npe.
Labeling txoj hauj lwm hloov
1.Txoj haujlwm daim ntawv lo yog txiav txim siab los ntawm qhov yuav tsum tau ua ntawm lub workpiece, thiab cov jig sib raug yog tsim. Pem hauv ntej, nraub qaum, sab laug, thiab txoj cai sau npe tuaj yeem hloov kho los ntawm kev txav lub jig.
2.Qhov siab hloov cov kauj ruam:
Tig qhov kev xaiv hloov mus rau phau ntawv.
Manually thawb daim ntawv lo tev lub tog raj kheej mus rau sab xis.
Manually nias down lub suction thiab labeling cylinders ntawm lub taub hau suction.
Kho qhov chaw ntawm lub workpiece kom txog li 2 hli siab dua li daim txhuam cev ntawm lub taub hau nqus.
Cov txheej txheem sau npe
- Manually tso lub workpiece rau ntawm jig.
- Nias lub ko taw hloov.
- Lub tshuab cia li siv daim ntawv lo.
- Manually tshem tawm cov ntawv sau ua haujlwm. (Lub voj voog no rov ua dua.)
Feem ntau faults thiab teeb meem ntawm semi-automatic high-precision flat labeling tshuab
1. Lub taub hau nqus tsis tuaj yeem tuav daim ntawv lo
- Tsis txaus cua siab (nce cua siab).
- Lub qhov nqus dej yog thaiv (ntxuav lub qhov cua).
Lub taub hau suction thiab daim ntawv lo stripping phaj tsis sib npaug (kho qhov parallelism).
2. Daim ntawv lo strip yog deviated
- Qhov txwv rings nyob rau tib sab tsis nyob rau hauv tib lub dav hlau (xoos lub txwv rings, cia daim ntawv lo strip txav li ntawm 0.5 meters, ces kho qhov txwv rings).
- Daim ntawv lo stripping phaj yog skewed (hloov qhov txwv txwv thiab txwv lub nplhaib ntawm daim ntawv lo stripping txoj hauj lwm).
3. Nruam daim ntawv lo
- Nruam daim ntawv lo thiab tsis tiav daim ntawv lo muaj feem xyuam rau qhov rhiab heev ntawm qhov muag pom hluav taws xob. Koj tuaj yeem kho qhov rhiab heev. Thov xa mus rau txoj kev hloov kho hauv tshooj dhau los ntawm kev kho qhov muag hluav taws xob.
- Yog tias qhov teeb meem tshwm sim tom qab kho lub qhov muag hluav taws xob, daim ntawv lo yuav ua tau ntau tshaj qhov siv tau ntawm lub qhov muag hluav taws xob xaiv, lossis lub qhov muag hluav taws xob yuav raug puas tsuaj, xav tau kev sab laj nrog cov chaw tsim khoom.
- Lwm qhov ua tau yog tias daim ntawv lo siv yog deviated, ua rau lub qhov muag hluav taws xob tsis pom daim ntawv lo. Kho lub qhov muag hluav taws xob mus rau txoj haujlwm kom pom tseeb.
- Cov ntawv hauv qab xoob lossis qis qis qis tuaj yeem yog vim kev swb ntawm cov txheej txheem traction. Yog hais tias qhov traction ceev yog tsawg heev, nws yuav daws tau qhov teeb meem.
- Yog hais tias lub traction mechanism plam, nruj nreem ntsia hlau rau ntawm lub traction roller kom txog rau thaum daim ntawv hauv qab tsis plam lawm.
- Tsis tas li ntawd, xyuas seb qhov kev sib kis ntawm txoj siv tom qab tau txais cov ncej puas lawm.
4. Cov ntawv hauv qab tawg
- Cov ntawv hauv qab tawg yog zoo sib xws rau qhov zoo ntawm daim ntawv lo hauv qab daim ntawv, khawb thaum lub sij hawm daim ntawv lo traction, thiab daim ntawv adhesion.
- Xyuas seb daim ntawv hauv qab puas raug txiav. Yog tias muaj, nws yog qhov tsim nyog los hloov nws nrog cov ntawv zoo hauv qab. Nws raug nquahu kom siv glassine hauv qab ntawv thiab nug tus neeg muag khoom daim ntawv lo kom tswj tau qhov tob tob kom tsis txhob ua rau daim ntawv hauv qab.
- Xyuas seb daim ntawv lo yog khawb thaum nws txoj kev thiab tshem tawm tej yam uas ua rau khawb.
Yog tias daim ntawv lo yog adhered, nws yuav tsim kua muag tau yooj yim. Tswj qhov ntev ntawm daim ntawv lo tom ntej kom paub tseeb tias nws tsis lo rau cov khoom uas tau sau tseg.
5. Labeling sib txawv tshaj 2 hli
Label deviation muaj feem xyuam rau qhov sib txawv ntawm daim ntawv lo siv, slippage ntawm daim ntawv lo siv thiab traction log, qhov khoom tsis raug qhov chaw nrhiav pom, los yog daim ntawv lo tsis aligning kom raug nrog cov khoom raws li daim ntawv lo rau cov menyuam. Tshawb xyuas cov xwm txheej hauv qab no thiab hais txog lawv raws li:
- Yog hais tias daim ntawv lo siv yog deviated, loosen lub traction mechanism, rub daim ntawv rov qab thiab tawm, thiab cia nws cia li khiav ncaj. Thaum nws ncaj, clamp lub nplhaib txwv ntawm ob sab los coj daim ntawv lo.
- traction log slippage yuav tshwm sim los ntawm hnav ntawm lub log los yog loosening ntawm lub log locking ntsia hlau. Ob leeg tuaj yeem kho tau los ntawm kev zawm cov ntsia hlau xauv.
- Yam khoom yuam kev: Kev tsim cov ntug yuam kev tuaj yeem ua rau daim ntawv lo sib txawv. Qhov no tsuas yog daws tau los ntawm kev tswj cov khoom zoo.
Semi-Automatic High-Precision Flat Labeling Tshuab - Cov khoom siv tu
Kev tu thiab tu cov cuab yeej siv
1.Cov khoom siv installation thiab siv ib puag ncig: Lub tshuab yuav tsum tau ua nyob rau hauv ib chav tsev kub. Tsis txhob siv nws nyob rau hauv kub, av noo, acidic, los yog alkaline tej yam kev mob rau ncua sij hawm, vim qhov no yuav cuam tshuam rau cov cuab yeej siv lub neej, efficiency, thiab raug.
Khaws lub tshuab kom huv si: Tom qab siv, cov khoom xws li kev sib txhuam cov menyuam thiab lub thawv hluav taws xob yuav tsum tau muab ntxuav. Cawv lossis cov tshuaj ntxuav muag uas muaj nyob hauv lag luam tuaj yeem siv los ntxuav thiab tu.
Kev ceev faj rau kev ntxuav:
A. Tsis txhob siv cov cuab yeej ntxuav uas tuaj yeem ua rau lub tshuab ua kom puas.
B. Tsis txhob siv cov khoom siv yas corrosive.
C. Tsis txhob siv cov kua qaub acidic.
D.Kev tshuaj xyuas thiab kev saib xyuas tsis tu ncua: Lub tshuab yuav tsum tau tshuaj xyuas tsis tu ncua kom ntseeg tau tias kev ua haujlwm ib txwm muaj, npog, tab sis tsis txwv rau, cov hauv qab no:
- Ntxuav cov ntawv pov tseg thiab cov khib nyiab pov tseg.
- Tshem cov roj seem ntawm cov menyuam thiab cov npoo.
- Ntxuav lub lens sensor nrog txhuam mos los yog ntaub.
- Hloov lub fuse ib ntus. Txij li thaum lub tshuab siv AC lub zog, lub fuse yuav tsum tau siv los tiv thaiv overload.
- Kev saib xyuas tiv thaiv xeb: Siv cov roj los tiv thaiv xeb rau txhua qhov stainless hlau thiab hlau, thiab maj mam so nrog cov ntaub mos muag. Nws raug nquahu kom siv Ohm -40 roj los tiv thaiv xeb.
